TE18 Full Size Lightbar

Overview

The TE18 series full-size light bars are super slim and narrow, equipped with the brightest LEDs. It is streamlined and designed to minimize air resistance. They are designed to provide versatile and powerful warning illumination for police patrol vehicles, law enforcement SUVs, smaller tow trucks, and smaller construction vehicles. They can be mounted either permanently to the vehicle or with the use of an optional roof mounting kit.

Features

  • Super slim and narrow
  • Virtually no RFI/EMI radiation
  • Fully encapsulated for moisture, vibration, and corrosion resistance
  • High-intensity LEDs provide consistent warning performance
  • The strong polycarbonate cover and lens are finely molded with a streamlined appearance
  • Innovative thermal design reduces stress on LEDs during extended dwell time
  • 13 Flash patterns and can be customized
  • 360°light coverage with strong overall visual effects
  • 2-year warranty
Get A Quote
  • Specifications
  • Approvals ECE R10/ECE R65 Class 2/CISPR25 Class 3/SAE J845 Class 1
    Module length  152 cm/ 59.84 inches
    Operating voltage 12/24V
    Operating temperature  -30℃~ +65℃
    Wires Red: Positive(+)
    Black: Negative(-)
    Yellow: Pattern Switch
    Cable length 5000mm cable
    Base Extruded aluminum
    Cover PC
    Lens PC
    Mounting Bracket
    Waterproof IP67
    Net weight 8 modules:3,440g/PC(bracket included); Each additional module,  increase in weight 340g
    Packing (6 modules) Carton Size: 936x150x50 mm
    Packing (8 modules) Carton Size: 1240x150x50 mm
    Qty.: 1 set/Carton
    Warranty 2 Years
    Remarks Lens/ Takedowns/ Alleys can be customized
