  • W801 series full size LED light bar with 2 modules
  • W801 series full size LED light bar with 3 modules
  • W801 series full size LED light bar with 4 modules
  • W801 series full size LED light bar with 5 modules
  • W801 series full size LED light bar with 6 modules
  • W801 series full size LED light bar with 8 modules
  • W801 series full size LED light bar with 7 modules
  • W801 series full size LED light bar with 9 modules
  • W801 series full size LED light bar with 10 modules
  • W801 series full size LED light bar with 11 modules
  • W801 series full size LED light bar with 13 modules
  • W801 series full size LED light bar with 12 modules
  • W801 series full size LED light bar Amber color top view
  • W801 series full size LED light bar Amber color side view
  • W801 series full size LED light bar Amber color front view

W801 Full Size Lightbar

Overview

W801 series full-size light bars are slim and streamline designed with low air resistance. They are designed to provide versatile and powerful warning illumination for police patrol vehicles, law enforcement SUVs, smaller tow trucks, smaller construction vehicles, and more. They can be mounted either permanently to the vehicle or using an optional roof mounting kit.

Features

  • ECE R10 (EMC), SAE J845 Class 1, and CISPR 25 Class 3 certified, with virtually no RFI/EMI radiation
  • Fully encapsulated for moisture, vibration, and corrosion resistance
  • LED arrays support consistent warning performance
  • The strong polycarbonate cover and lens are finely molded, giving them a streamlined appearance
  • Innovative thermal design reduces stress on LEDs during extended periods of use
  • Standard mounting feet with a swiveling angle of +/- 5° for adjusting the lightbar
  • 12 optional flash patterns can be customized
  • 360-degree light coverage with strong overall visual effects
  • 2-year warranty
Get A Quote
  • Specifications
  • Approvals ECE R10/CISPR 25 Class3/ECE R65 Class 1/SAE J845 Class 1
    Module length 7.87 inches
    Operating voltage 12/24V
    Operating temperature  -30℃~ +65℃
    Wires Red: Positive(+)
    Black: Negative(-)
    Yellow: Pattern Switch
    Cable length 5000mm cable
    Base Extruded aluminum
    Cover PC
    Lens PC
    Mounting Bracket
    Waterproof IP67
    Net weight 4 modules:3,920g/PC(bracket included); Each additional module,  increase in weight 950g.
    Packing (7 modules) Carton Size: 1450x266x55 mm
    Packing (8 modules) Carton Size: 1640x266x55 mm
    Qty.: 1 set/Carton
    Warranty 2 Years
    Remarks Lens/ Takedowns/ Alleys can be customized.
